MOLEX 5034801400
MOLEX 5034801400

MOLEX 5034801400

Manufacturer No:

5034801400

Manufacturer:

MOLEX

Package:

Description:

BackFlip, Easy-On 503480 Series FFC, FPC Contacts, Top and Bottom Tape & Reel (TR) 0.020 0.50mm Solder 14 Positions Surface Mount, Right Angle Gold -40°C~85°C 0.5A

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

5034801400 information

MOLEX 5034801400 technical specifications, attributes, parameters and parts with similar specifications to MOLEX 5034801400.

  • Type
  • Parameter
  • Factory Lead Time
  • 10 Weeks
  • Contact Material
  • Phosphor Bronze
  • Mounting Type
  • Surface Mount, Right Angle
  • Housing Material
  • Liquid Crystal Polymer (LCP), Glass Filled
  • Mounting Option 1
  • LOCKING
  • Actuator Material
  • Polyamide (PA), Nylon, Glass Filled
  • Board Mounting Option
  • FITTING NAIL
  • Operating Temperature
  • -40°C~85°C
  • Packaging
  • Tape & Reel (TR)
  • Series
  • BackFlip, Easy-On 503480
  • Published
  • 2014
  • Feature
  • Solder Retention
  • Pbfree Code
  • yes
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Termination
  • Solder
  • ECCN Code
  • EAR99
  • Connector Type
  • FFC/FPC CONNECTOR
  • Number of Positions
  • 14
  • Number of Rows
  • 1
  • Voltage - Rated
  • 50V
  • Additional Feature
  • ROHS COMPLIANT
  • HTS Code
  • 8536.69.40.51
  • Subcategory
  • Headers and Edge Type Connectors
  • Pitch
  • 0.020 0.50mm
  • Total Number of Contacts
  • 14
  • Reference Standard
  • UL
  • Contact Finish
  • Gold
  • Reliability
  • COMMERCIAL
  • Body Length or Diameter
  • 0.343 inch
  • Number Of PCB Rows
  • 1
  • PCB Contact Pattern
  • RECTANGULAR
  • Body Breadth
  • 0.039 inch
  • Housing Color
  • White
  • Contact Style
  • BELLOWED TYPE
  • Insulation Resistance
  • 50000000Ohm
  • Dielectric Withstanding Voltage
  • 200VAC V
  • Contact Pattern
  • RECTANGULAR
  • Mating Cycles
  • 10
  • Flat Flex Type
  • FFC, FPC
  • Connector/Contact Type
  • Contacts, Top and Bottom
  • Cable End Type
  • Straight, Tapered
  • Locking Feature
  • Flip Lock, Backlock
  • Actuator Color
  • Black
  • Contact Finish Thickness
  • 3.94?in 0.10?m
  • Height Above Board
  • 0.039 1.00mm
  • FFC, FCB Thickness
  • 0.30mm

Download datasheets and manufacturer documentation for MOLEX 5034801400.

Datasheets:

Environmental Information:

PCN Obsolescence/ EOL:

PCN Assembly/Origin:

PCN Other:

3D Drawings:

5034801400 Overview


Packaging is in the form of FFC/FPC CONNECTOR.The mounting type of the device is Surface Mount, Right Angle.A Tape & Reel (TR) case is used to package the product.A product of the BackFlip, Easy-On 503480 Series, it belongs to the range of products of that series.Furthermore, there are other features available, such as ROHS COMPLIANT, to name a few.A number of features make the Solder Retention feature more powerful.-40°C~85°C Operating Temperature is the default operating temperature for the device.

5034801400 Features


BackFlip, Easy-On 503480 series


5034801400 Applications


There are a lot of Molex
5034801400 FFC, FPC (Flat Flexible) Connectors applications.


  • Automotive Electronics
  • Telecommunications
  • Data Technology
  • Blowers
  • Control panels
  • Electrical substations
  • Energy efficient lighting (LED)
  • LED municipal outdoor and street lighting
  • All Electrical Machinery
  • Refrigeration control

User Guide
