Manufacturer No:

5025840470

Manufacturer:

MOLEX

Package:

Description:

1 Rows Receptacle Solder Copper Alloy Surface Mount Tape & Reel (TR) Tin Resin 4 Positions Forked

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

5025840470 information

MOLEX 5025840470 technical specifications, attributes, parameters and parts with similar specifications to MOLEX 5025840470.

  • Type
  • Parameter
  • Factory Lead Time
  • 10 Weeks
  • Contact Material
  • Copper Alloy
  • Mounting Type
  • Surface Mount
  • Insulation Material
  • Resin
  • Mounting Option 1
  • LOCKING
  • Operating Temperature
  • -40°C~105°C
  • Packaging
  • Tape & Reel (TR)
  • Series
  • CLIK-Mate 502584
  • Published
  • 2010
  • Feature
  • Pick and Place, Solder Retention
  • Pbfree Code
  • yes
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Termination
  • Solder
  • Connector Type
  • Receptacle
  • Number of Positions
  • 4
  • Applications
  • Automotive, General Purpose, Industrial, Lighting, Medical
  • Number of Rows
  • 1
  • Additional Feature
  • ROHS COMPLIANT, TAPE AND REEL
  • Fastening Type
  • Latch Holder
  • Subcategory
  • Headers and Edge Type Connectors
  • Contact Finish - Mating
  • Tin
  • MIL Conformance
  • NO
  • DIN Conformance
  • NO
  • Filter Feature
  • NO
  • Contact Type
  • Forked
  • Mixed Contacts
  • NO
  • Total Number of Contacts
  • 4
  • Insulation Height
  • 0.285 7.25mm
  • Style
  • Board to Cable/Wire
  • Number of Positions Loaded
  • All
  • Pitch - Mating
  • 0.059 1.50mm
  • Insulation Color
  • Beige
  • Number of Conductors
  • ONE
  • Reference Standard
  • UL
  • Reliability
  • COMMERCIAL
  • Number Of PCB Rows
  • 1
  • PCB Contact Pattern
  • RECTANGULAR
  • Body Breadth
  • 0.25 inch
  • Contact Gender
  • FEMALE
  • Body Depth
  • 0.285 inch
  • Rated Current (Signal)
  • 2A
  • Contact Resistance
  • 20mOhm
  • Insulation Resistance
  • 500000000Ohm
  • Mating Contact Pitch
  • 0.059 inch
  • Polarization Key
  • POLARIZED HOUSING
  • Dielectric Withstanding Voltage
  • 500VAC V

Download datasheets and manufacturer documentation for MOLEX 5025840470.

Datasheets:

Environmental Information:

3D Drawings:

5025840470 Overview


This product is packaged in a Receptacle box.Surface Mount indicates that the device is mounted.An Tape & Reel (TR) case is utilized for packaging the product.The product is a part of the CLIK-Mate 502584 Series.Furthermore, there are other features such as ROHS COMPLIANT, TAPE AND REEL, to name a few.There is the possibility of using the device for Automotive, General Purpose, Industrial, Lighting, Medical.In many ways, Pick and Place, Solder Retention makes it more powerful.Operating temperature is set to -40°C~105°C.
