Adafruit Industries LLC 4065

Manufacturer No:

4065

Manufacturer:

Adafruit Industries LLC

Package:

16-SMD Module

Description:

2.412GHz~2.484GHz WiFi -40°C~125°C 2.5V~3.6V ADC, GPIO, I2C, I2S, PWM, SDIO, SPI, UART, USB Integrated, Trace 72.2Mbps 21.5dBm 802.11b/g/n -98dBm 16-SMD Module

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

4065 information

Adafruit Industries LLC 4065 technical specifications, attributes, parameters and parts with similar specifications to Adafruit Industries LLC 4065.

Type
Parameter

Mounting Type
Surface Mount

Package / Case
16-SMD Module

Operating Temperature
-40°C~125°C

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Voltage - Supply
2.5V~3.6V

Frequency
2.412GHz~2.484GHz

Memory Size
1MB Flash

Data Rate
72.2Mbps

Utilized IC / Part
ESP8266

Protocol
802.11b/g/n

Power - Output
21.5dBm

RF Family/Standard
WiFi

Antenna Type
Integrated, Trace

Sensitivity
-98dBm

Serial Interfaces
ADC, GPIO, I2C, I2S, PWM, SDIO, SPI, UART, USB

Current - Receiving
50mA~56mA

Current - Transmitting
120mA~170mA

Modulation
64-QAM, BPSK, CCK, DSSS, OFDM

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for Adafruit Industries LLC 4065.

Datasheets:

adafruitindustriesllc-4065-datasheets-0782.pdf

4065 Overview

It adopts the way of Surface Mount for RF Transceiver' mounting.When operating, Transceiver's operating temperature should be kept at -40°C~125°C.The RF Transceiver can supply 2.5V~3.6V voltage.The RF Transceiver Module operates at a frequency of 2.412GHz~2.484GHz.

4065 Features

Surface Mount
2.5V~3.6V volts

4065 Applications

There are a lot of Adafruit Industries LLC
4065 RF Transceiver Modules applications.

Low-power IoT applications
LoT applications
Power Amplifier (PA)
Low Noise Amplifier (LNA)
Transmit
Receive
Switch
Power management
Internet of Things (IoT)
Secure Payment
