Tallysman Wireless Inc. 33-3872-01-01

Manufacturer No:

33-3872-01-01

Manufacturer:

Package:

Description:

6 Bands Dome UHF 1GHz~2GHz Panel Mount TNC Female 1.2276GHz 1.248GHz 1.561GHz 1.575GHz 1.589GHz 1.602GHz 3.8dBi, 4.5dBi 0.827 21.00mm Beidou, Galileo, GLONASS, GPS

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

33-3872-01-01 information

Tallysman Wireless Inc. 33-3872-01-01 technical specifications, attributes, parameters and parts with similar specifications to Tallysman Wireless Inc. 33-3872-01-01.

Type
Parameter

Factory Lead Time
4 Weeks

Mounting Type
Panel Mount

Series
Accutenna®

Feature
LNA

Part Status
Active

Moisture Sensitivity Level (MSL)
Not Applicable

Termination
TNC Female

Applications
Beidou, Galileo, GLONASS, GPS

Ingress Protection
IP67

Gain
3.8dBi, 4.5dBi

Frequency Range
1.213GHz~1.261GHz 1.557GHz~1.606GHz

RF Family/Standard
Navigation

Antenna Type
Dome

VSWR
1.8

Number of Bands
6

Frequency Group
UHF 1GHz~2GHz

Frequency (Center/Band)
1.2276GHz 1.248GHz 1.561GHz 1.575GHz 1.589GHz 1.602GHz

Height (Max)
0.827 21.00mm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for Tallysman Wireless Inc. 33-3872-01-01.

Datasheets:

tallysmanwirelessinc-3338720101-datasheets-0178.pdf

tallysmanwirelessinc-335340031005-datasheets-3104.pdf

33-3872-01-01 Overview

It is suitable for general RF Antennas when it is set to Panel Mount.There is a Antenna RF in the Accutenna® series.

33-3872-01-01 Features

With Panel Mount
Accutenna® series

33-3872-01-01 Applications

There are a lot of Tallysman Wireless Inc.
33-3872-01-01 RF Antennas applications.

Lightings
Rectifiers
Inverters
Satellites
Transmission
Cellphones
Laptops
Marine Navigation
Avionics
GPS
