ROHM Semiconductor 2SCR554PFRAT100
ROHM Semiconductor 2SCR554PFRAT100

ROHM Semiconductor 2SCR554PFRAT100

Manufacturer No:

2SCR554PFRAT100

Manufacturer:

ROHM Semiconductor

Package:

TO-243AA

Description:

NPN 150°C TJ 1?A ICBO 1 Elements 3 Terminations SILICON NPN TO-243AA Cut Tape (CT) Surface Mount

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

2SCR554PFRAT100 information

ROHM Semiconductor 2SCR554PFRAT100 technical specifications, attributes, parameters and parts with similar specifications to ROHM Semiconductor 2SCR554PFRAT100.

  • Type
  • Parameter
  • Factory Lead Time
  • 13 Weeks
  • Mounting Type
  • Surface Mount
  • Package / Case
  • TO-243AA
  • Surface Mount
  • YES
  • Number of Pins
  • 3
  • Transistor Element Material
  • SILICON
  • Operating Temperature
  • 150°C TJ
  • Packaging
  • Cut Tape (CT)
  • Series
  • Automotive, AEC-Q101
  • Published
  • 2016
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 3
  • ECCN Code
  • EAR99
  • Max Power Dissipation
  • 500mW
  • Terminal Position
  • SINGLE
  • Terminal Form
  • FLAT
  • Peak Reflow Temperature (Cel)
  • NOT SPECIFIED
  • Reach Compliance Code
  • not_compliant
  • Time@Peak Reflow Temperature-Max (s)
  • NOT SPECIFIED
  • Number of Elements
  • 1
  • Configuration
  • SINGLE
  • Case Connection
  • COLLECTOR
  • Power - Max
  • 500mW
  • Polarity/Channel Type
  • NPN
  • Transistor Type
  • NPN
  • DC Current Gain (hFE) (Min) @ Ic, Vce
  • 120 @ 100mA 3V
  • Current - Collector Cutoff (Max)
  • 1?A ICBO
  • Vce Saturation (Max) @ Ib, Ic
  • 350mV @ 25mA, 500mA
  • Collector Emitter Breakdown Voltage
  • 80V
  • Current - Collector (Ic) (Max)
  • 1.5A
  • Transition Frequency
  • 300MHz
  • Frequency - Transition
  • 300MHz
  • REACH SVHC
  • Unknown
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for ROHM Semiconductor 2SCR554PFRAT100.

Other Related Documents:

PCN Design/Specification:

2SCR554PFRAT100 Overview


As explained above, DC current gain takes into account the rate at which the base current flows through the collector current; therefore, DC current gain for this device is 120 @ 100mA 3V.In VCE saturation, Ic is at its maximum value (saturated), and the vce saturation (Max) is 350mV @ 25mA, 500mA.The part has a transition frequency of 300MHz.

2SCR554PFRAT100 Features


the DC current gain for this device is 120 @ 100mA 3V
the vce saturation(Max) is 350mV @ 25mA, 500mA
a transition frequency of 300MHz


2SCR554PFRAT100 Applications


There are a lot of ROHM Semiconductor
2SCR554PFRAT100 applications of single BJT transistors.
