2N2222AUATXV information

TT Electronics 2N2222AUATXV technical specifications, attributes, parameters and parts with similar specifications to TT Electronics 2N2222AUATXV.

  • Type
  • Parameter
  • Factory Lead Time
  • 25 Weeks
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 4-CLCC
  • Number of Pins
  • 4
  • Supplier Device Package
  • 4-CLCC (5.59x3.81)
  • Operating Temperature
  • -65°C~200°C TJ
  • Packaging
  • Bulk
  • Published
  • 2007
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Max Operating Temperature
  • 200°C
  • Min Operating Temperature
  • -65°C
  • Max Power Dissipation
  • 500mW
  • Power Dissipation
  • 500mW
  • Power - Max
  • 500mW
  • Transistor Type
  • NPN
  • Collector Emitter Voltage (VCEO)
  • 300mV
  • Max Collector Current
  • 800mA
  • DC Current Gain (hFE) (Min) @ Ic, Vce
  • 75 @ 1mA 10V
  • Current - Collector Cutoff (Max)
  • 10nA ICBO
  • Vce Saturation (Max) @ Ib, Ic
  • 300mV @ 15mA, 150mA
  • Collector Emitter Breakdown Voltage
  • 50V
  • Voltage - Collector Emitter Breakdown (Max)
  • 50V
  • Collector Emitter Saturation Voltage
  • 1V
  • Collector Base Voltage (VCBO)
  • 75V
  • Emitter Base Voltage (VEBO)
  • 6V
  • Height
  • 1.905mm
  • Length
  • 5.715mm
  • Width
  • 3.937mm
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for TT Electronics 2N2222AUATXV.

Datasheets:

2N2222AUATXV Overview


The DC current gain is the ratio of the base current to the collector current ?dc = Ic/Ib and the DC current gain for this device is 75 @ 1mA 10V.With a collector emitter saturation voltage of 1V, it offers maximum design flexibility.Vce saturation means Ic is at its maximum value(saturated), and the vce saturation(Max) is 300mV @ 15mA, 150mA.If the emitter base voltage is kept at 6V, a high level of efficiency can be achieved.The product comes in the supplier device package of 4-CLCC (5.59x3.81).A 50V maximal voltage - Collector Emitter Breakdown is present in the device.Collector current can be as low as 800mA volts at its maximum.

2N2222AUATXV Features


the DC current gain for this device is 75 @ 1mA 10V
a collector emitter saturation voltage of 1V
the vce saturation(Max) is 300mV @ 15mA, 150mA
the emitter base voltage is kept at 6V
the supplier device package of 4-CLCC (5.59x3.81)


2N2222AUATXV Applications


There are a lot of TT Electronics/Optek Technology
2N2222AUATXV applications of single BJT transistors.


  • Inverter
  • Interface
  • Driver
  • Muting
