Manufacturer No:

20310509101

Manufacturer:

HARTING

Package:

Module, Single Pass Through

Description:

Hall Effect, Closed Loop Sensor 1-Channel Bidirectional -40°C~85°C 15V~24V 500A Accuracy-±1% Linearity-±0.1%

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

20310509101 information

HARTING 20310509101 technical specifications, attributes, parameters and parts with similar specifications to HARTING 20310509101.

  • Type
  • Parameter
  • Factory Lead Time
  • 15 Weeks
  • Mount
  • Chassis Mount
  • Mounting Type
  • Chassis Mount
  • Package / Case
  • Module, Single Pass Through
  • Operating Temperature
  • -40°C~85°C
  • Packaging
  • Bulk
  • Pbfree Code
  • yes
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Voltage - Supply
  • 15V~24V
  • Output
  • Ratiometric, Voltage
  • Number of Channels
  • 1
  • Operating Supply Current
  • 35mA
  • Polarization
  • Bidirectional
  • Max Supply Current
  • 35mA
  • Accuracy
  • ±1%
  • Response Time
  • 1?s
  • Sensor Type
  • Hall Effect, Closed Loop
  • Linearity
  • ±0.1%
  • Max Supply Voltage (DC)
  • 24V
  • Min Supply Voltage (DC)
  • 15V
  • For Measuring
  • AC/DC
  • Current - Sensing
  • 500A
  • REACH SVHC
  • No SVHC

Download datasheets and manufacturer documentation for HARTING 20310509101.

Datasheets:

ConflictMineralStatement:

20310509101 Overview


Module, Single Pass Through packages are used for the safety protection of current sensors. In order to protect these current sensors from damage, they are packaged in the Bulk. There should be no current greater than 35mA coming from current sensors. The sensors should provide voltages not less than 15V in DC circuits. Nevertheless, the DC circuit voltage should not exceed 24V when the current sensors are being used. As these electronic components operate, they should supply 35mA current.
