Switchcraft Inc. 12B

Manufacturer No:

12B

Manufacturer:

Switchcraft Inc.

Package:

Description:

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

12B information

Switchcraft Inc. 12B technical specifications, attributes, parameters and parts with similar specifications to Switchcraft Inc. 12B.

Type
Parameter

Factory Lead Time
8 Weeks

Contact Material
Copper Alloy

Mount
Chassis, Chassis Mount, Panel, Through Hole

Mounting Type
Panel Mount, Through Hole

Housing Material
Plastic

Weight
11.793402g

Body Material
Copper Alloy

Contact Material - Plating
Nickel

Operating Temperature
-20°C~65°C

Packaging
Bulk

Series
LITTEL-JAX®

Feature
Mounting Hardware, Thread Lock

Part Status
Active

Moisture Sensitivity Level (MSL)
Not Applicable

Number of Terminations
3

Termination
Solder Eyelet(s)

ECCN Code
EAR99

Connector Type
Phone Jack

Gender
Female

Voltage - Rated
25VDC

Contact Finish - Mating
NOT SPECIFIED

MIL Conformance
NO

DIN Conformance
NO

IEC Conformance
NO

Orientation
Straight

Shielding
Unshielded

Depth
32.41mm

Current Rating
1A

Housing Color
Silver

Max Current Rating
1A

Number of Ports
1

Number of Poles
3

Max Voltage Rating (DC)
25V

Thread Size
3/8-32

Number of Positions/Contacts
3 Conductors, 3 Contacts

Includes
3 pcs - 1 Connector, 1 Nut, 1 Washer

Internal Switch(s)
Does Not Contain Switch

Panel Hole Size
0.375 9.52mm

Industry Recognized Mating Diameter
6.35mm (0.250, 1/4) - Headphone

Actual Diameter
0.250 (6.35mm)

Signal Lines
Stereo (3 Conductor, TRS)

Height
12.7mm

Length
19.05mm

Width
63.5mm

REACH SVHC
No SVHC

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for Switchcraft Inc. 12B.

Description:
Switchcraft Barrel - Audio Connectors 12B are stereo 6.35mm panel mount jacks. They are designed to provide reliable and secure connections for audio applications.

Features:
- Stereo 6.35mm panel mount jacks
- Nickel-plated brass construction
- Gold-plated contacts
- Threaded mounting nut
- Solder terminals
- RoHS compliant

Applications:
Switchcraft Barrel - Audio Connectors 12B are suitable for a variety of audio applications, including professional audio equipment, musical instruments, and consumer electronics. They are also suitable for use in audio/video systems, home theater systems, and other audio/visual applications.
