TE Connectivity 1-1825002-3

Manufacturer No:

1-1825002-3

Manufacturer:

TE Connectivity

Package:

Description:

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

1-1825002-3 information

TE Connectivity 1-1825002-3 technical specifications, attributes, parameters and parts with similar specifications to TE Connectivity 1-1825002-3.

Type
Parameter

Lifecycle Status
ACTIVE (Last Updated: 5 days ago)

Factory Lead Time
33 Weeks

Contact Material
Copper Alloy

Mount
PCB, Through Hole

Mounting Type
Through Hole

Housing Material
Polyphenylene

Body Material
Polyphenylene Sulfide (PPS)

Actuator Material
Polyamide

Operating Temperature
-30°C~85°C

Packaging
Tube

Series
ADF

Published
2008

JESD-609 Code
e4

Pbfree Code
yes

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Termination
PC Pins

ECCN Code
EAR99

Type
Switch

Number of Positions
8

Voltage - Rated
24VDC

Voltage - Rated DC
5V

Pitch
0.100 2.54mm Full

Orientation
Straight

Depth
8.38mm

Contact Finish
Gold

Termination Style
PC Pin

Body Breadth
7.49 mm

Actuator Type
Slide (Standard)

Housing Color
Black

Lead Length
4mm

Circuit
SPST

Contact Resistance
50mOhm

Insulation Resistance
1000000000Ohm

Contact Current(DC)-Max
0.1A

ELV
Compliant

Max Current Rating
100mA

Dielectric Withstanding Voltage
500VRMS V

Electrical Life
1,000 Cycles

Max Voltage Rating (DC)
24V

Mechanical Life
1,000 Cycles

Contact Current Rating
100mA

Number of Switch Sections
8

PCB Hole Count
8

Actuator Color
WHITE

Contact Function
ON-OFF

Washable
Yes

Download datasheets and manufacturer documentation for TE Connectivity 1-1825002-3.
