HARTING 09651626816

Manufacturer No:

09651626816

Manufacturer:

HARTING

Package:

Description:

D-Sub Plug, Male Pins Male Signal Solder 1 DE E Through Hole, Right Angle Copper Alloy Steel

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

09651626816 information

HARTING 09651626816 technical specifications, attributes, parameters and parts with similar specifications to HARTING 09651626816.

Type
Parameter

Factory Lead Time
4 Weeks

Contact Material
Copper Alloy

Contact Plating
Gold

Mount
Through Hole

Mounting Type
Through Hole, Right Angle

Dielectric Material
Polybutylene Terephthalate (PBT), Polyester, Glass Filled

Housing Material
Polybutylene

Shell Material, Finish
Steel

Operating Temperature
-55°C~125°C

Packaging
Bag

Feature
Board Lock, Grounding Indents

Pbfree Code
yes

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
9

Termination
Solder

Connector Type
Plug, Male Pins

Number of Rows
2

Gender
Male

Subcategory
D Type Connectors

Contact Finish - Mating
NOT SPECIFIED

MIL Conformance
NO

DIN Conformance
YES

IEC Conformance
YES

Contact Type
Signal

Mixed Contacts
NO

Option
GENERAL PURPOSE

Current Rating (Amps)
6.5A

Total Number of Contacts
9

Orientation
Right Angle

Current Rating
6A

Shell Finish
TIN

Reference Standard
UL

Reliability
COMMERCIAL

Number Of PCB Rows
2

PCB Contact Pattern
STAGGERED

Mating Information
MULTIPLE MATING PARTS AVAILABLE

Empty Shell
NO

Insulation Resistance
5000000000Ohm

Flange Feature
Housing/Shell (4-40)

Body/Shell Style
RECEPTACLE

Connector Style
D-Sub

Number of Ports
1

Contact Form
Stamped

Shell Size, Connector Layout
1 DE E

Backset Spacing
0.409 (10.40mm)

Test Voltage
1kV
