Rosenberger 08K243-40ME3
Manufacturer No:
08K243-40ME3
Manufacturer:
Package:
Description:
Jack, Female Socket Threaded 50Ohm 1.85mm Solder 1 Port Polyetheretherketone (PEEK); Polytetrafluoroethylene (PTFE) -55°C~125°C
Quantity:
Delivery:
Payment:
In Stock :Available
Price not displayed? Please send an RFQ, and we will respond immediately.
08K243-40ME3 information
Rosenberger 08K243-40ME3 technical specifications, attributes, parameters and parts with similar specifications to Rosenberger 08K243-40ME3.
- Type
- Parameter
- Factory Lead Time
- 13 Weeks
- Mounting Type
- Board Edge, End Launch
- Dielectric Material
- Polyetheretherketone (PEEK); Polytetrafluoroethylene (PTFE)
- Body Material
- Brass
- Mounting Option 1
- LOCKING
- Center Contact Plating
- Gold
- Center Contact Material
- Beryllium Copper
- Operating Temperature
- -55°C~125°C
- Series
- RPC
- Published
- 2018
- Feature
- Mounting Hardware
- Part Status
- Active
- Moisture Sensitivity Level (MSL)
- 1 (Unlimited)
- Connector Type
- Jack, Female Socket
- Voltage - Rated
- 150V
- Fastening Type
- Threaded
- Subcategory
- Other RF Connectors
- Total Number of Contacts
- 1
- Reliability
- COMMERCIAL
- Body Depth
- 0.606 inch
- Contact Style
- COAX
- Contact Resistance
- 4mOhm
- Impedance
- 50Ohm
- Connector Style
- 1.85mm
- Frequency (Max)
- 70GHz
- Mating Cycles
- 500
- Contact Termination
- Solder
- Includes
- 3 pcs - 1 Connector, 2 Screws
- Operating Frequency-Max
- 70GHz
- Insertion Loss
- 0.05 dB
- Shield Termination
- Screw
- RoHS Status
- RoHS Compliant
Download datasheets and manufacturer documentation for Rosenberger 08K243-40ME3.
Datasheets:
08K243-40ME3 Overview
The product is packaged in Jack, Female Socket.Board Edge, End Launch is the mounting type.As a product of the RPC Series, it can be found in this category.A variety of tasks can be managed via its 1 ports.With its Mounting Hardware feature, it is more powerful in many ways.The device is operating at -55°C~125°C Operating Temperature.
08K243-40ME3 Features
RPC series
08K243-40ME3 Applications
There are a lot of Rosenberger
08K243-40ME3 Coaxial Connectors applications.
- Measuring & Control Technology
- Instrumentation
- Automotive Electronics
- Telecommunications
- Data Technology
- Blowers
- Control panels
- Electrical substations
- Energy efficient lighting (LED)
- LED municipal outdoor and street lighting
